With raw materials metal and non-metal powders, our equipment presses these powders into various shapes under intense pressure. These powders can be processed include graphite, ceramic, magnesium zinc, nickel zinc, manganese zinc, iron zinc, iron silicon, iron silicon aluminum, aluminum oxide (ceramic), calcium carbonate ceramic, silicon carbide, vermilion, gemstones, black gallstone, turquoise powder, and various medicinal and edible powders. It is suitable for applications with magnetic components, electronic devices, precision ceramics, mechanical parts, food processing and artisanal crafts which require powder forming molding.
Equipped with our original high-precision powder metallurgy mold and the third-generation pressure maintaining system, not only retains the consistently excellent forming effect, but also boosts production efficiency by 3-5%.
For clients who need premium molding process, our new generation powder molding machines is a significant achievement. Equipment with an advanced packing system, the finish products are benefit with better precision, more uniform density, and enhanced durability.
All components are made by high-strength materials, logical structure, and precise fitting. The maintenance becomes simply due to modular design.
Machine type | Female length (mm) | Molding diameter (mm) | Pressure (ton) | Motor power (kw) | Speed (r/min, frequency conversion) | Dimension (length * width * height) mm | Net weight (kg) |
160-P-17A | 17 | 1-6 | 0.8 | 0.75 | 5-26 | 566*544*1218 | 395 |
200-P-31A | 31 | 1-10 | 2 | 1.5 | 5-25 | 634*696*1808 | 550 |
200-P-31B/C | 31 | 1-12 | 2 | 1.5 | 10-25 | 696*627*1727 | 650 |
250-P-44A | 44 | 1-12 | 7 | 2.2 | 8-20.5 | 745*700*1790 | 950 |
300-P-31A | 31 | 1-20 | 10 | 5.5 | 6-15 | 830*826*1625 | 1150 |
300-P-55A | 55 | 1-20 | 10 | 5.5 | 6-15 | 843*826*1717 | 1250 |
300-P-55B/C | 55 | 1-20 | 10 | 5.5 | 6-15 | 832*826*1839 | 1550 |
300-P-55 Gravity type | 55 | 1-20 | 10 | 5.5 | 4-10 | 832*826*1839 | 1700 |
300-P-75A | 75 | 1-20 | 10 | 5.5 | 6-15 | 845*826*1946 | 1400 |
400-P-31-20C | 31 | 1-12 | 2 | 15 | 8-18 | 1098*1024*1850 | 2950 |
400-P-60-16C | 60 | 1-20 | 20 | 15 | 6-13 | 1152*1024*2245 | 3800 |
400-P-110-16C | 110 | 1-20 | 20 | 15 | 6-13 | 1152*1024*2382 | 4592 |
400-P-60-12C | 60 | 1-30 | 20 | 11 | 4-11.5 | 1152*1024*2245 | 3890 |
400-P-60B/C | 60 | 40 | 20 | 11 | 4-11.5 | 1152*1024*2245 | 3850 |
400-P-60 | 60 | 1-40 | 20 | 11 | 4-8 | 1152*1024*2244 | 3900 |
400P-90/110A | 90/110 | 1-40 | 20 | 11 | 4-11.5 | 1152*1024*2377 | 3200 |
400-P-110C | 110 | 1-40 | 20 | 11 | 4-11.5 | 1152*1024*2382 | 4400 |
530-P-60B/C | 60 | 2-50 | 25 | 15 | 4-10.5 | 1186*1214*2415 | 4850 |
530-P-60 | 60 | 2-22 | 25 | 15 | 3-7 | 1186*1214*2445 | 5300 |
530-P-90/110BC | 90/110 | 2-50 | 25 | 15 | 4-10.5 | 1186*1214*2542 | 5100 |
640-P-60A | 60 | 2-65 | 40 | 22 | 4-10.5 | 1444*1490*2592 | 7700 |
800-P-60A | 60 | 2-60 | 60 | 30 | 2-4.5 | 1700*1792*2850 | 13500 |
*For the latest technology and machine type, please feel free to contact with us.
HESHI
Powder molding
in a flash.
BOLUO HESHI MOULD MANUFACTURING CO.,LTD
Shuangjiang Village, Guangshan Road(S) Changning Town,Boluo County, Huizhou, Guangdong, China
Phone+0086 189 4822 1750 | http://www.heshi-auto.com/| http://www.heshi-auto.com/ | 18948221750@163.com
Prev : none
Next : none
Please feel free to contact us for any inquiries or customization requests regarding Powder compaction presses and molds. Our team is dedicated to providing you with professional and efficient service.
